Clock Generation Unit MLK-5-CLK

A device that inputs terrestrial digital broadcast TS and generates 10 MHz / 8.127 MHz clock signals.

  • By combining it with our ISDB-T demodulator “DMB-2-ISDBT,” a TTL backup configuration for MFN operation can be built.
  • The clock can be switched between 10 MHz and 8.127 MHz.
  • An optional configuration also supports F-SYNC output.

TTL Backup Configuration Image for MFN Operation

Specifications

Product TypeClock Generation Unit
Product NameTS CaPID MLT-5-CLK
Model NumberMLT5-A12HR-CLK
Input / OutputTS INDVB-ASI×1
TS OUT

DVB-ASI×2

  • Output impedance: 75Ω
  • OUT1 / OUT2 output identical signals
10.000MHz
OUT

BNC-J×2

  • Output impedance: 50Ω
  • Voltage level: 0.7 Vp-p
  • Switchable to 8.127 MHz (512/63 MHz) output
Contact OUT

D-sub 9-pin / MOS FET relay output

[Relay Specification]

  • Maximum output voltage: 40V
  • Continuous load current: Max. 120mA
    ON
  • resistance: Typical 1.0–15Ω (Max. 25Ω)
Power AC 100V–240V
Apparent Power20VA or less
Power Consumption12W or less
Operating Temperature / Humidity
  • 0–40°C
  • 30–80% RH (non-condensing)
Dimensions (W × H × D)
  • EIA 19-inch rack, 1U half size
  • 205 × 43.5 × 250 mm (excluding protrusions)
WeightApprox. 1.5 kg
Accessories
  • Power cable (AC100V)
  • User manual
Options
  • Rack-mount support angle U-1 (mount one unit in 1U)
  • Rack-mount support angle U-2 (mount two linked units in 1U)
Related ProductISDB-T Demodulator (DMB-2-ISDBT)
