Supports both B-CAS and TRMP for descrambling
- A descrambler designed for terrestrial digital broadcasting.
- Supports descrambling via both B-CAS and TRMP.
- Equipped with alarm contact output terminals for outputting contact signals related to TS comparison results and device anomalies.
- Also allows the RS data in the descrambled TS to be replaced.
- Additionally equipped with a function to compare descrambling results.
- All settings can be changed using the front panel buttons.
- Supports low-latency descrambling (0.1 ms or less), and comes with a dedicated application.
Specifications
| Product Type | B-CAS / TRMP Compatible Descrambler | ||
|---|---|---|---|
| Product Name | TS CaPID DSCR-T | ||
| Model Number | DSCRT-A130HR | ||
| I/O | Input | DVB-ASI × 1 (75Ω / Auto recognition of burst mode & packet mode) Card slot (for CAS) × 1 Hardware key slot × 1 | |
| Output | DVB-ASI × 3 (75Ω / Packet mode only) ※ Selectable between B-CAS / TRMP / Through output Delay: 0.1 ms or less | ||
| Contact Output | D-Sub 9-pin female × 1 (Close on fault × 6) ※ Photo MOS relay contact output | ||
| Control | LAN × 1 | ||
| Power Supply | AC 100–240 V | ||
| Apparent Power | 17 VA | ||
| Power Consumption | 11 W | ||
| Operating Temperature & Humidity | 5–45°C, 30–80% (no condensation) | ||
| Dimensions (W × H × D) | EIA 19-inch rack 1U half-size | ||
| Weight | Approx. 1.5 kg | ||
| Accessories | Power cable (AC 100 V) Instruction manual Hardware key (standard SD card size) | ||
| Optional Accessories (Sold Separately) | Rack mount support angle U-1 (for mounting 1 unit as 1U) Rack mount support angle U-2 (for mounting 2 units in tandem as 1U) | ||
| Related Products | ISDB-T Demodulator (DMB-2-ISDBT) | ||
